Push-Pull Connectors Prevent Accidental Disconnects
To eliminate the possibility of mission-critical circumstances being adversely affected by unintentional disconnections, push-pull connectors have been developed. Since its initial successful debut, push-pull connectors have shown their ability to function in challenging environments across a broad range of applications and in several different industries.
How Push-Pull Connectors Actually Function
Using a robust, self-latching mechanism in push-pull connectors makes it possible to prevent inadvertent disconnections effectively. This mechanism enables the connector to be mated by simply pushing the plug into the socket. However, you will not be able to dislodge the connection by by pushing on it.
Instead, to effectively break the connection, the connector’s body must be compressed while the cable is being pulled. In contrast to connectors that employ a normal screw thread or bayonet locking method, push-pull connections only need an axial force to mate an inmate, as opposed to the more common rotating force. The end product is a locking mechanism that is simple yet reliable.
Typical Characteristics Exhibited by Push-Pull Connectors
The design of the vast majority of push pull connectors is circular, although these connectors may also be square or rectangular depending on the needs of the application. Because making connections and disconnections with the circular connector only requires two fingers, it is possible to put many connectors close to one another, which results in substantial space savings. In addition, working with circular push-pull connections in the field does not need any specialised equipment, which makes the process both quick and simple.
Despite their reduced weight and the fact that they may be fabricated from either plastics or metals, push-pull connections continue to provide a solution that is both tough and long-lasting, even in the most pressing of circumstances. They are suitable for use in both indoor and outdoor settings, and they may be sealed to an IP68 standard, making them resistant to dust, vibration, and shock and allowing for complete water submersion. Push-pull connections may also be built as disposable devices in cases where sterility and cleanliness are of the utmost importance. The requirements of the application will determine whether or not this is possible.
Uses for Push-Pull Connectors in Various Applications
The need for push-pull connectors may be found in various applications, including the medical field and the military and communications industries. They find usage in various applications, such as military vehicles, medical devices and equipment, instrumentation, and soldier wearables, where it is vital to have a connection that can be made and broken quickly while maintaining a high level of security. These mission-critical applications need a very dependable connection since the consequences of accidentally being disconnected might be pretty severe.
In addition, push-pull connectors are perfect for usage in circumstances where the connections must not only be simple to use but also be able to survive many mating cycles. For instance, those who work in the medical field must be able to connect and detach various equipment on a timely manner successfully and regularly during emergency scenarios.
LEMO B Series
One series of push-pull connections developed for indoor or vacuum-tight applications is called the LEMO B Series. These connectors are often used in test and measurement, instrumentation, medical equipment, and audio/video systems. They feature a modular insert architecture that allows them to accommodate a wide variety of high-density or hybrid electrical contacts. These contacts may include solder, crimp, PCB straight or elbow, fibre, coax, thermocouple, pneumatic, fluidic, or high-voltage connections
SOURIAU JBX Series
The SOURIAU JBX Series is a metal push-pull connection that offers a variety of contact configuration choices that include both power and signal contacts. These connectors are available with IP68 sealing in both the mated and unmated states, making them excellent for use in demanding outdoor applications that require temporary or continuous protection against dust and water immersion. The SOURIAU JBX Series is often used in various industries, including telecommunications, building automation control, robotics, and medical devices.
Your Source for Push-Pull Connectors at PEI-Genesis
Allow the professionals at PEI-Genesis to guide you through the process of specifying a push-pull connection for your design when the time comes. PEI-Genesis will help you identify the ideal push-pull connection solution for your project, whether it’s a life-or-death military application or a piece of medical equipment that must endure sterilising treatments.
